Economical type
Economical drag chain control cable with PUR sheath
Economical drag chain control cable with PUR sheath
PUR sheath, PVC insulation, extrusion type structure.
No extrusion inner sheath, using the lapping type as the wrap way
Conductors: Type 6 copper wire. which has the high performance as the same as SF series
This kind of the cable is mainly used in indoors environment, the maximum speed can reach 2m/s, the maximum stroke 10m, 5m is the best distance, the minimum bending radius 10 times, oil resistance, low temperature resistance, mobile use of the lowest temperature of -10℃, fixed installation for -20℃, hydraulic oil resistance (outdoor use cable can be customized).
Suitable for using in the industry: machine tool, engraving machine, plasma cutting machine, small laser cutting machine, etc
The Model For PUR Sheath
Our model:EF120/EF220 (Application:Control/Power)
Our model:EF120/EF220 (Application:Control/Power)
Our model:EF321 (Application:Servo)
Our model:EF421 (Application:Data)
Economical drag chain control cable with PVC sheath
Economical drag chain control cable with PVC sheath
PVC sheath, PVC insulation, extrusion structure.
No extrusion inner sheath, using the lapping type as the wrap way
Conductors: Type 6 copper wire. which has the high performance as the same as SF series
This kind of cable is mainly used in indoors environment, the maximum speed can reach 2m/s, the maximum stroke is 10m, the best distance is within 5m, the minimum bending radius is 10 times, the low temperature resistance is general, the minimum temperature for mobile use is -5℃, the fixed installation is -20℃, oil resistance (oil resistance cable can be customized).
Suitable for using in the industry: machine tool, engraving machine, plasma cutting machine, small laser cutting machine, etc
The Model For PVC Sheath
Our model:EF110/EF210 (Application:Control/Power)
Our model:EF111/EF211 (Application:Control/Power - Shield)
Our model:EF311 (Application:Servo)
Our model:EF411 (Application:Data)
