SYV Coaxial Cable

Short Description:

Product Model: SYV Coaxial Cable

Execution standard:

Product features:

1) Rated voltage:

2) Temperature resistance: -15~70

3) Conductor: bare copper wire/tinned wire

4) Insulation: PE

5) Shielding: bare copper wire/tinned wire

6) Sheath: PVC


Product Detail

FAQ

Product Tags

Features/uses:

Excellent corrosion resistance, oil resistance, strong acid, strong alkali resistance, strong oxidant, etc. Excellent electrical insulation performance, high voltage resistance, low loss at high frequency, no moisture absorption, large insulation resistance; With excellent fire resistance, aging resistance, high temperature resistance, anti attenuation, stable transmission, long service life.

Application:

Antenna, TV, radar, RADIO frequency, monitoring, computer, instrumentation, etc

RG-EN



Model Inner conductor  mm Insulation mm Jacket mm Resistance Ω
SYV-50-2-1 1/0.68 2.2 4 50
SYV-50-2-2 7/0.16 1.5 2.8 50
SYV-50-3-1 1/0.9 2.95 5 50
SYV-50-3-2 7/0.32 2.95 5 50
SYV-50-5-1 1/1.4 4.8 7.2 50
SYV-50-5-1 1/1.40 4.8 7.2 50
SYV-50-7-2 7/0.75 7.25 10.3 50
SYV-50-9 7/0.95 9 12.2 50
SYV-50-12 7/1.15 11.5 15 50
SYV-75-4-1 1/0.59 3.7 6 75
SYV-75-4-2 7/0.21 3.7 6.07 75
SYV-75-5-1 1/0.75 4.8 7.2 75
SYV-75-5-2 7/0.26 4.8 7.2 75
SYV-75-7-1 1/1.15 7.25 10.3 75
SYV-75-7-2 7/0.40 7.25 10.3 75
SYV-75-9 1/1.37 9 12.2 75
SYV-75-12 7/0.63 11.5 15 75
