GN800

Short Description:

▪Conductor: Pure nickel
▪AWG Size: 22 AWG~3/0 AWG,stranded or solid conductor
▪Insulation: Mica tape+Quartz fiber lapping + Quartz fiber braiding
▪Temperature range:-60~600℃(800℃ short time)
▪Rated voltage:300V/500V
▪Braiding Colour:Natural


Product Detail

FAQ

Product Tags

Options:

 ▪ Shield (optional): Pure nickel wire or stainless steel braiding

Characteristics:

▪ Pure nickel stranded wire, has good high temperature oxidation resistance.

▪ Mica tape has excellent high temperature resistance and combustion resistance, good insulation performance.

Application:

It is used in high-temperature operation fields such as electric heating, petrochemicals, mechanical and electrical equipment, power plants, drying tunnels, drying rooms, heating light sources, and electric appliances.

Code

GN800

Voltage

300V/500V

Temp

600℃(800 short time

Cross sections
semm2

Ω

OD(mm)

Weight
(KG/KM)

0.50

160.40

3.6

12.53

0.75

106.80

3.8

16.35

1.0

80.00

4.1

19.40

1.5

64.80

4.5

26.20

2.0

42.00

4.8

35.20

2.5

32.80

5.1

41.50

4

20.40

5.6

75.60

6

13.60

6.5

99.10

10

7.80

7.6

131.10

16

4.96

9.0

200.80

25

3.18

10.5

292.80

35

2.26

12.5

377.50

50

1.58

13.2

516.90

75

1.11

15.6

697.10

95

0.84

17.6

736.50
