FEP 200℃

Short Description:

▪Insulation:FEP
▪Temperature range:-80~200℃
▪Conductor:Silver plated copper
▪36AWG~10AWG,stranded or solid.
▪Rated voltage:150V/300V/600V
▪Compliance UL file E252215


Product Detail

FAQ

Product Tags

Options:

▪ -X: tinned copper conductor

▪ -N: nicked copper conductor

▪ Colour:red / yellow / blue / white / black / yellow green / brown, etc.

(Two-color insulation/ Surface marking)

Characteristics:

▪ RoHS Compliant

▪ UL 758 Appliance Wiring Material

▪ Maximum length of a piece of wire: 4 kilometers

▪ Flame retardant grade: UL1581 (VW-1),IEC 60332-1-2

▪ Perfect mechanical and chemical properties

Application:

It can be used in automotive sensors, motors, air conditioners,  microwave ovens, electronic disinfection cabinets, electricity Internal  wiring for heaters, electric ovens, electric woks, lighting fixtures, etc.

UL code

10485

10362

1727

Voltage

600V

600V

600V

Temp

250

250

250

AWG

Ω

OD(inches)

Weight
(KG/KM)

OD(inches)

Weight
(KG/KM)

OD(inches)

Weight
(KG/KM)

10

3.55





0.1390

55.92

0.1587

62.75

12

5.64





0.1169

38.29

0.1366

44.10

14

8.96





0.0933

22.89

0.1130

27.62

16

14.60





0.0795

15.75

0.0992

19.85

17

18.30





0.0717

12.28

0.0913

16.01

18

23.20





0.0657

9.96

0.0854

13.43

20

36.70

0.0480

5.70

0.0559

6.66

0.0756

9.67

22

59.40

0.0441

4.65

0.0520

5.53

0.0717

8.36

24

94.20

0.0362

2.92

0.0441

3.65

0.0638

6.13

26

150.00

0.0315

2.04

0.0394

2.69

0.0591

4.95

28

239.00

0.0268

1.33

0.0346

1.90

0.0543

3.94

30

381.00

0.0244

1.04

0.0323

1.56

0.0520

3.49

32

664.80

0.0220

0.79





0.0496

3.09

34

948.38

0.0197

0.58









36

1500.98

0.0185

0.49







After twenty years development, the group holds two industrial parks in Shanghai, areas where the economy has been greatly developed, covering a total land area of 20 thousand square meters. Shenyuan has serviced to 15000 customers,focus on providing customers with comprehensive solutions.
