Silicone Wire 200℃

Short Description:

▪Conductor:Tin plated copper
▪Temperature range:-60~200℃
▪28AWG~300mm²,stranded or solid
▪Insulation:Extruded Silicone Rubber
▪Rated voltage:300V/600V
▪Compliance UL file E252215


Product Detail

FAQ

Product Tags

Options:

▪ -J: High-strength silicone rubber,Tear-resistant

▪ -ZR: high flame retardant silicone rubber,meet FT1

▪ -TR: Ultra-fine tinned copper stranded wire (IEC 60228, category 6 standard / class 6)

▪ Colour:red / yellow / blue / white / black / yellow green / brown, etc.

▪ Or matte-finish  (Two-color insulation/ Surface marking)

Characteristics:

▪ RoHS Compliant

▪ High temperature resistance

▪ UL 758 Appliance Wiring Material

▪ Flame retardant grade: UL1581 (FT2)

▪ Excellent environmental protection, odorless and non-toxic,

▪ Excellent antithrombotic,biological inertia and electrical insulation properties

▪ Soft silicone rubber , good elasticity, excellent bending performance, and can be used removable.

Application:

The products are widely used in electrical wiring harnesses, sensing lines, PTC thermistors, coating equipment, automotive internal connection lines, motors, lighting fixtures, electronic appliances, voltage cabinets, high-voltage motors, and other fields.

UL code

3132

3529

Voltage

300V

600V

Temp

150

150

AWG

Ω

OD(inches)

Weight
(KG/KM)

OD(inches)

Weight
(KG/KM)

12

5.64





0.1677

42.32

14

8.96





0.1362

27.55

16

14.60

0.0898

15.51

0.1205

19.44

17

18.30

0.0835

11.86

0.1126

15.55

18

23.20

0.0780

10.49

0.1087

13.97

20

36.70

0.0685

7.20

0.0992

10.33

22

59.40

0.0614

5.16

0.0921

8.03

24

94.20

0.0543

3.49

0.0850

6.09

26

150.00

0.0496

2.58

0.0803

5.01

28

239.00

0.0449

1.84

0.0756

4.08

30

381.00

0.0425

1.52

0.0732

3.68

After twenty years development, the group holds two industrial parks in Shanghai, areas where the economy has been greatly developed, covering a total land area of 20 thousand square meters. Shenyuan has serviced to 15000 customers,focus on providing customers with comprehensive solutions.
